What are the bases for installing road traffic signal lights?

LED traffic signal lights are a type of traffic lights used to allocate effective right-of-way to conflicting traffic flows, so as to improve road traffic safety and road capacity. They generally consist of red lights, green lights, and yellow lights. The red light indicates no passage, the green light indicates permission to pass, and the yellow light indicates a warning. In the current specifications, the regulations regarding the bases for installing LED traffic signal lights are too general. Then, what are the bases for installing road traffic signal lights? The following will introduce them to you.

(1) When the road width is greater than 15m, that is, at intersections where there are more than four lanes for the mixed traffic of motor vehicles and non-motor vehicles, and the peak hourly traffic flow at the intersection exceeds 1,200 vehicles, motor vehicle signal lights should be installed.

(2) At intersections where motor vehicle lane traffic signal lights are installed, when there are 3 or more approach lanes at the intersection and there are left-turn, straight-ahead, and right-turn guiding lanes on the ground, lane control should be implemented, and lane signal lights should be installed.

(3) At intersections where motor vehicle lane LED signal lights are installed, when the intersection is an intersection of two-way four-lane roads with two-way four-lane roads, and the left-turn traffic flow of the approach lane in one direction accounts for more than 15% of the traffic flow of that approach lane, a three-phase control should be adopted; when the left-turn traffic flows of the approach lanes in both directions exceed 15% of the traffic flow of their respective approach lanes, a four-phase control should be adopted.

(4) At intersections where motor vehicle lane LED signal lights are installed, when the intersection is an intersection of a two-way four-lane road with a two-way six-lane road or a two-way eight-lane road, for the two-way four-lane direction, according to the size of the left-turn traffic flow, when the left-turn traffic flow exceeds 15% of the traffic flow of this approach lane, a separate left-turn phase should also be adopted.

(5) For three-fork intersections, when setting the phases of LED traffic signal lights, the coordination of left turns, straight-ahead movements, and right turns at the entire intersection, as well as the safety of pedestrians crossing the street, should be fully considered. Currently, in many cities, a three-phase control is adopted for the signal lights at three-fork intersections. This control method brings great potential safety hazards to pedestrians crossing the street, and the traffic order at the entire intersection is chaotic, making accidents prone to occur.

 About Shenzhen Starlight Road Technology Co., Ltd.:
Established in 2011, Shenzhen Starlight Road Technology Co., Ltd. is a national high-tech enterprise specializing in the R&D, production, and sales of intelligent traffic products. With 15 years of dedication and relentless effort, the company has accumulated extensive experience. Its main products include:

• Intersection Smart Networked traffic Signal Controller with English operation interface
• Single-Point Intersection Traffic Signal Controller
• LED Traffic Signal Lights
• LED Countdown Timer
• Smart Crosswalk Alert Beacon
• Integrated Traffic Signal Lights
• Sectional Pedestrian Crossing Request System
• Voice Prompt Device (Blind Clock)
• Mobile radar speed check sign
• Solar-powered radar speed feedback sign
• Solar-powered radar speed sign with vehicle license plate recognition
• Portable solar-powered traffic signal light
• Solar-powered warning traffic signal light
• Smart zebra crossing Road-embedded cast iron road stud
• LED Smart crosswalk Road-embedded cast iron Block
• Smart zebra crossing pavement-embedded pedestrian signal light
• LED Canopy Warning Signal Light
• LED Traffic Guidance Display Screen
• Smart Curve Safety Detection System

In addition, the LED traffic signal lights of Starlight Road have been exported to many overseas countries and regions. For example: Traffic signal lights in Cancun, Mexico; Solar-powered traffic signal lights in Guanajuato, Mexico; Traffic signal lights in Bangkok, Thailand; Solar-powered traffic signal lights in Chiang Mai, Thailand; Traffic signal lights in Riyadh, Saudi Arabia; Traffic warning lights in Kuala Lumpur, Malaysia; Traffic warning lights in Penang, Malaysia; Traffic signal lights in Vietnam; Traffic signal lights in Indonesia; Traffic signal lights in Cambodia; Traffic signal lights in the Philippines; Traffic signal lights in Laos; Traffic signal lights in Myanmar; Traffic signal lights in Brunei; Traffic signal lights in Turkmenabat, Turkmenistan; Traffic signal lights in Dashoguz, Turkmenistan; Traffic signal lights in Mary, Turkmenistan; Solar-powered traffic signal lights in Salto, Uruguay; Traffic signal lights in Fray Bentos, Uruguay; Traffic warning lights in São Paulo, Brazil; Traffic warning lights in Rio de Janeiro, Brazil; Traffic warning lights in Brasília, Brazil; Traffic signal lights in Salvador, Brazil; Traffic signal lights in Fortaleza, Brazil; Traffic signal lights in Dili, Timor-Leste; Traffic signal lights in Baucau, Timor-Leste; Traffic signal lights in Maliana, Timor-Leste; Traffic signal lights in Suai, Timor-Leste; Traffic signal lights in Madrid, Spain; Traffic signal lights in Barcelona, Spain; Traffic signal lights in Seville, Spain; Traffic signal lights in Málaga, Spain; Traffic signal lights in Alicante, Spain; Traffic signal lights in Ronda, Spain; Traffic signal lights in Doha, Qatar; Solar-powered traffic signal lights in Al Khor, Qatar; Traffic signal lights in Dhoby Ghaut, Singapore; Warning lights in Tampines, Singapore; Warning lights in Woodlands, Singapore; Warning lights in The Shoppes at Marina Bay Sands, Singapore; Traffic signal lights in Al Ahmadi, Kuwait; Traffic signal lights in Bandar Seri Begawan, Brunei; Traffic signal lights in Belait, Brunei; Traffic warning lights in Tel Aviv, Israel; Traffic warning lights in Haifa, Israel; Traffic warning lights in Manama, Bahrain; Solar-powered traffic signal lights in Muharraq, Bahrain; Solar-powered traffic signal lights in Dubai, the United Arab Emirates; Traffic signal lights in Abu Dhabi, the United Arab Emirates; Traffic signal lights in Ajman, the United Arab Emirates; Traffic signal lights in Johannesburg, South Africa; Traffic signal lights in Cape Town, South Africa; Traffic signal lights in Baghdad, Iraq; Traffic signal lights in Basra, Iraq; Traffic signal lights in Mosul, Iraq.

For more information on intelligent traffic solutions, please visit the Starlight Road ITS official website: //www.starlightroadits.com/ or contact us via email.
