Smart Intelligent Networked Traffic Signal Controller
Multi-Mode Control: Adaptive, coordinated, GPS-synced green waves.
IoT-Ready: 4G/GPS/Beidou integration for real-time cloud management.
Extreme Durability: -20°C to +65°C operation, IP54-rated.
Energy Efficient: <20W base power consumption.
Manual Override: Wireless remote control within 100m.
Pedestrian Priority: 4+ crosswalk request inputs.
Anti-Phantom Tech: Eliminates green-light conflicts.
Global Compliance: EN12368, CE, RoHS, ISO9001 certified.
5-Year Warranty: Industrial-grade components.
| Control Modes | Adaptive, Coordinated, Timed, Manual, Flashing Yellow |
| Output Channels | 36/48/96 (Max 6.3A per channel) |
| Processor | ARM7 96MHz/32-bit, 32MB RAM |
| Communication | 10/100M Ethernet, RS232/485, 4G/GPS |
| Voltage Range | AC220V ±20%, 50Hz ±2Hz |
| Operating Temp. | -20°C to +65°C |
| Humidity Tolerance | 45%-90% RH (Non-condensing) |
| Insulation Resistance | >100MΩ @1500V/1min |
| Dimensions | 540×540×1065mm (36/48ch), 690×540×1315mm (96ch) |
| Certifications | EN12368, CE, RoHS, ISO9001, GB14887 |
Smart Intelligent Networked Traffic Signal Controller
The Smart Intelligent Networked Traffic Signal Controller revolutionizes intersection management with its phase-based adaptive algorithms. Designed for T-junctions, multi-leg crossings, and highway ramps, it dynamically adjusts signal timing using vehicle detection inputs while maintaining fail-safe modes like all-red or yellow flash. The modular design supports 36-96 signal outputs, enabling seamless coordination across smart city networks via 4G/GPS synchronization.
Adaptive Green-Wave Optimization
Real-time adjusts green ratios using vehicle/pedestrian detection data.
Reduces congestion by 25% during peak hours in field tests.
Why it matters: Cuts fuel waste and emissions at complex intersections.
Cableless Coordination
GPS timing correction without physical wiring.
Remote diagnostics via Starlight 4G IoT Cloud Platform traffic management.
Why it matters: Slashes maintenance cost by 40% vs traditional systems.
Extreme Environment Ready
-20°C Arctic-grade capacitors prevent cold-start failures.
Dustproof IP54 housing survives sandstorms/monsoons.
Why it matters: Trusted by Dubai and Oslo municipal authorities.
Smart Failure Recovery
Auto-reverts to timed/flashing modes during network outages.
Downgrades to priority-based modes during unrecoverable faults.
Why it matters: Ensures 99.99% uptime for critical junctions.
Pedestrian-Centric Design
Extra 4+ Pedestrian crossing request input trigger control
Extends walk times when Pedestrian crossing are detected.
Why it matters: 30% fewer pedestrian incidents in pilot cities.
Applications
Urban Smart Corridors: Coordinate signals across 10+ intersections.
Highway Merge Zones: Prevent bottlenecks at toll plazas/ramps.
School/EMS Priority Routes: Green-light preemption for emergency vehicles.
Pedestrian Malls: Dynamic timing for foot traffic peaks.
WHY CHOOSE US
AS YOUR LED TRAFFIC Signal Solution MANUFACTURER?
Your Trusted Partner in Traffic Signal Solutions-Manufacturing Quality Signals Since 2013,As a specialized manufacturer of road traffic lights compliant with China GB14887-2011 standards, and international standards such as CE, RoHS, EN12368, and ISO9001.Can meet the highest global standards for safety, durability, and environmental compliance.
Starlight Road provides durable, cost-effective signaling products for urban intersections, pedestrian crossings and traffic control systems.It is suitable for cross, T and other intersections, controlled by traffic signal controller, to guide vehicles and pedestrians to pass safely and orderly. Functional categories include: "full ball signal light", "arrow light",”U-turn lights” "pedestrian light", "countdown light", "Bicycle-shaped lights" and "lane control signal light", 4G IoT Cloud Platform based Road Alert Tech Highway Adverse Weather Detection, Guidance and Alert System，Multifunctional Road Pre-Warning System，Radar Speed Signs，AI Smart Crosswalk Systems，etc. It is an important tool to strengthen the road traffic management, reduce the occurrence of traffic accidents, improve the efficiency of road use and the traffic conditions.
Our enterprise is ISO 9001:2015 certified. Starlight Road's product delivers great results that inspire confidence in our customers all through the guaranteed five-year warranty.
Vast experience in the field, knowledge of various standards, attentive pre- and post-sale service, and extended local technical assistance in specific areas.
As a traffic signal company, we offer a quick response to your requests and orders, quick delivery, automated SMT/DIP equipment, and effective assembly production lines. Delivery time of our traffic signals products is within 5 days.
In 2021, we launched a 4G IoT Cloud Platform to enable remote management and predictive maintenance for all connected devices. By June 2024, this platform will fully support real-time monitoring of our entire product ecosystem.
4. Starlight Road traffic signal light manufacturer integrates cutting-edge technology into every product, ensuring reliable and efficient traffic solutions. Such as we revolutionary used Embedded base for LED Crosswalk Block / Road Studs,make out them can hold 50-80 ton trucks.
Our solutions are tailored to meet specific traffic management needs, providing flexibility and adaptability.
